The right equipment available at the right time.
38 Special Stump Grinder
Technical Specifications:
Specifications
- Engine: 40HP BriggsGas
- Weight: 750lbs
- Length: 49”
- Height: 50”
- Width: 35”
- Revolution Grinding Wheel or Green Teeth Wheels
- Under 36“ wide
- 6’ wide adjustable chip guards 20” cutting depth
- Mounting plates for ALL Mini & Full Sized Wheel Loaders & Skid Steers
- Dual Arc Cylinders
- 6 Gallon Fuel Tank
- 2” Over-Sized cutter wheel shaft for increased durability
- 4-Groove Direct Drive Sheaves and belt
- 2” American made Heavy Duty Bearings
- 3 Tie-Down Points
- Stands on its own
- 1 year Branch Manager Warranty
- 2-year Kohler Engine Warranty
Cutter Wheel
- Diameter: 20”
- Thickness: 1/2”
- Cutting Depth: 20”
- Cutting Height: 24”
- Cutter Head Swing: 42” Arc
Loader Description:
3 Types of Wheels to Choose From:
38 Special Performance Wheel
From Branch Manager Attachments with Green Manufacturing 900 Series Teeth, this wheel has been engineered specifically for our 38 Special Engine Driven Stump Grinder Attachment.
- Our wheel utilizes 16 Wearsharp® teeth, allowing you to rotate each tooth to gain a fresh cutting edge and increase your uptime.
- The concave shape of the Wearsharp® teeth means that the teeth will maintain an edge while it wears down instead of rounding over like a traditional tooth.
- GREEN-SEIZE™ is used to ensure easy serviceability.
- All Tooth Holders are Grade 8 heat treated and easily replaceable.
The Revolution
From New River Equipment Corp., utilizes the industry’s best cutting tool while reducing wheel wear.
- Precise alignment of all cutting tools for superior cutting and wheel balance.
- Locating pin system on pockets (wear pads) to insure correct placement on the wheel every time.
- Low profile and beveled pocket design that maximizes cutting efficiency.
- Unique pocket design protects the cutting wheel and is reversible for twice the pocket life.
The Quadwheel
This high-performance wheel uses the same technology as the Greenwheel®, but has two additional holders that will cut through your stump even faster!
The unique design of this wheel provides approximately a 15″ gap between each set of teeth. This provides several benefits:
- It allows you to start your cut farther into the stump.
- Only one set of teeth is engaged at once. The break before the next set of teeth passes through the stump gives your motor a chance to regain RPM before starting another cut.
- Uses only 4 holders, 12 Wearsharp® teeth & 8 bolts, decreasing your maintenance costs.
- Replaceable Tooth Holder is Grade 8 heat treated.
Purchase Options
If you would like more information on this unit or a quote to have one delivered you can either email or call us:
Email: admin@eandkinvestments.com
Phone:208-260-2501
Cell: 208-650-6990
Ask about our Lease - To - Own options
